Анализатор сигналов Signal Hound BB60C
The Signal Hound BB60C Real-Time RF Spectrum Analyzer and Recorder is a 9 kHz to 6 GHz Spectrum Analyzer and RF Recorder with an instantaneous bandwidth of 27 MHz, and sweep speeds of 24 GHz/sec.
- StandardTemperature Range: 0°C to +65°COption 1Temperature Range: -40°C to +65°C
- RF frequency range from 9 kHz to 6 GHz
- Up to 24 GHz/sec sweep speed
- Wide dynamic range from -158 dBm to +10 dBm
- Resolution bandwidths available from 10 Hz to 10 MHz
- Powered solely through USB, no external power supply needed
- Powerful digital signal processing happens on the PC
- Software and hardware included for one low price
- Use our API (Application Programming Interface) to develop your own applications
- Digitized IF Data at 80 million samples per second
- 27 MHz instantaneous bandwidth
- Compatible with Windows 7/8/10 64-bit operating systems
- USB 3.0 communications providing 140 MB/sec sustained throughput to PC
- Measures under 9 inches long
Галерея
Device dimensions
Weight 500 g
Dimensions 21.9 x 8.1 x 3 cm
Weight 500 g
Dimensions 21.9 x 8.1 x 3 cm
Product-in-packaging dimensions
Weight 830 g
Dimensions 26.04 x 13.8 x 7.95 cm
Weight 830 g
Dimensions 26.04 x 13.8 x 7.95 cm
