Анализатор сигналов Signal Hound SA44B
The Signal Hound SA44B is a Software Defined Receiver (SDR) optimized as a narrow-band real-time RF spectrum analyzer. It is a compact, simple to use, effective troubleshooting tool for the general lab user, engineering students, and ham radio enthusiast.
- StandardTemperature Range: 0°C to +70°COption 1Temperature Range: -40°C to +85°C
- RF Frequency Range: 1 Hz to 4.4 GHz
- Low noise amplifier available above 500 KHz
- Wide dynamic range: -151 dBm to +10 dBm
- Resolution bandwidths (RBW) of 0.1 Hz to 250 KHz and 5 MHz
- Includes a High Dynamic Range Measuring Receiver
- 0.25 dB relative accuracy
- 0 dBm to -125 dBm, 150 KHz to 1 GHz
- 0 dBm to -115 dBm, 1 GHz to 4.4 GHz
- Adjustable digital audio filters
- Accurate AM and FM measurements
- No external power supply needed – draws power from USB
- Powerful Digital Signal Processing happens on the PC
- Software and Hardware included for one low price
- Additional Third-Party Software Packages are available
- TSCM software is available, and is being marketed as “Kestrel TSCM Software”
- Write your own software with our free Application Programming Interface (API)
- I/Q Data up to a 240 KHz bandwidth
- Frequency Sweeps up to 140 MHz per second
- Compatible with Windows 7/8/10 32-bit and 64-bit operating systems.
- AM and FM Demodulation Measurements
- USB 2.0 communications at 480 MBPS
- Demodulates AM/FM/SSB/CW audio in real-time
- Automation capability using our API
- Measures 8 inches long
- Weighs 10 ounces
Галерея
Device dimensions
Weight 290 g
Dimensions 19.4 x 8 x 3 cm
Weight 290 g
Dimensions 19.4 x 8 x 3 cm
Product-in-packaging dimensions
Weight 600 g
Dimensions 23.5 x 13.8 x 7.95 cm
Weight 600 g
Dimensions 23.5 x 13.8 x 7.95 cm
