Анализатор сигналов Signal Hound SP145

Offering real-time analysis up to 14.5 GHz with ultra-fast sweep speeds in a portable form factor, the SP145 is your ideal RF analysis companion in the field and at the lab.

The SP145 is a high-performance, 14.5 GHz real-time spectrum analyzer and monitoring receiver featuring sweep speeds up to 200 GHz/sec, 40 MHz streaming bandwidth, -160 dBm displayed noise average, and an internal GPS for enhanced field measurements.
At-a-glance specs:

• 100 kHz to 14.5 GHz frequency range;
• Sweeps at 200 GHz/sec (at ≥70 kHz RBW);
• Calibrated Streaming I/Q: Up to 40 MHz of selectable I/Q streaming bandwidth;
• Connects to a PC for analysis (Spike spectrum analysis application included) via USB-C;
• Small form factor: 7.45″ x 4.51″ x 1.81″ (189mm x 115mm x 46mm) 1.1 lbs.(0.5 kg);
• Extended temperature range option available;
• Compatible with Windows or Linux, x64_86 architecture.
