Генератор сигналов Signal Hound TG124A
The Signal Hound TG124A is a 100 kHz to 12.4 GHz tracking generator which works with your SA124A to measure filters, attenuators, amplifiers and more! It is compact, simple to use, and an effective troubleshooting and analysis tool in the lab or in the field. Whether you are an amateur radio enthusiast or a microwave communications professional, the TG124A provides fast, accurate results.
- RF Frequency Range: 100 kHz to 12.4 GHz
- Amplitude range: -30 dBm to -12 dBm
- Up to 19 selectable frequency step sizes in a 1-2-5 sequence
- Step sizes, below 4 GHz: 10 Hz to 10 MHz steps
- Step sizes, above 4 GHz: 100 Hz to 10 MHz steps
- Sweep up to 700 frequency points per second with the SA124A
- No external power supply needed – draws power from USB
- Software and Hardware included for one low price
- Write your own software with our
- free Application Programming Interface (API)
- Compatible with the Windows operating systems
- Measures 8 inches long
- Weighs 10 ounces
- Includes 20 dB attenuator, p/n Mini-Circuits FW-20+
Галерея
Device dimensions
Weight 300 g
Dimensions 19.5 x 8 x 3 cm
Weight 300 g
Dimensions 19.5 x 8 x 3 cm
Product-in-packaging dimensions
Weight 700 g
Dimensions 23.5 x 13.8 x 7.95 cm
Weight 700 g
Dimensions 23.5 x 13.8 x 7.95 cm
