Генератор сигналов Signal Hound VSG25A

The VSG25A is a 100 MHz to 2.5 GHz vector signal generator, featuring a 12-bit I/Q baseband arbitrary waveform generator which can be clocked at virtually any frequency from 54 kHz to 180 MHz, and includes a 4096×16 bit pattern buffer for built-in or custom modulation.

The included software automatically generates:

• CW: 100 MHz to 2.5 GHz, -40 dBm to +10 dBm
• Unspecified operation down to 80 MHz, or -70 dBm to +13 dBm
• AM / FM: 30 Hz to 40 MHz modulation rates, sine, triangle, square, ramp
• Pulse: 6 ns to 25 ms width, 12 ns to 1 second period
• Multi-tone: Up to 1023 tones with optional center notch
• Use random phase + notch for Noise Power Ratio testing
• Use parabolic phase for best signal / noise
• PSK: BPSK, DBPSK, QPSK, OQPSK, DQPSK, π/4 DQPSK, 8-PSK, D8PSK, 16-PSK
• 4k to 45M symbols per second
• Optional raised cosine, root raised cosine filtering
• Up to 512 symbols, streamed continuously in a loop
• Binary symbol editor features 1-click insertion of PN7 / PN9 sequences
• QAM: QAM-16, QAM-64, QAM-256 (same features as PSK)
• ASK / FSK: 4k to 45M symbols per second
• Optional Gaussian filtering
• Up to 512 symbols, streamed continuously in a loop
• Sweep
• Arbitrary Custom Modulation
• Load a CSV file with I and Q values, specify center frequency, amplitude, pattern length (up to 2048), pattern period (up to 65535), and clock rate.
